A class to take in FiteredAnitaEvents and cross-correlate nearby channels. More...
#include <CrossCorrelator.h>
Public Member Functions | |
| virtual void | correlateEvent (const FilteredAnitaEvent *realEvent) |
| virtual void | correlateEvent (const FilteredAnitaEvent *realEvent, AnitaPol::AnitaPol_t pol) |
| void | doUpsampledCrossCorrelations (AnitaPol::AnitaPol_t pol, Int_t phiSector) |
| TGraph * | getCrossCorrelationGraph (AnitaPol::AnitaPol_t pol, Int_t ant1, Int_t ant2) const |
| TGraph * | getUpsampledCrossCorrelationGraph (AnitaPol::AnitaPol_t pol, Int_t ant1, Int_t ant2) const |
| TGraph * | getCrossCorrelationGraphWorker (Int_t numSamps, AnitaPol::AnitaPol_t pol, Int_t ant1, Int_t ant2) const |
| virtual Double_t | getCrossCorrelation (AnitaPol::AnitaPol_t pol, Int_t combo, Double_t deltaT) const |
| Double_t | getTimeOfMaximumUpsampledCrossCorrelation (AnitaPol::AnitaPol_t pol, Int_t ant1, Int_t ant2) const |
| void | initializeVariables () |
| void | getNormalizedInterpolatedTGraphs (const FilteredAnitaEvent *realEvent, AnitaPol::AnitaPol_t pol, bool raw=false) |
| void | renormalizeFourierDomain (AnitaPol::AnitaPol_t pol, Int_t ant) |
| void | doFFTs (AnitaPol::AnitaPol_t pol) |
| void | doCrossCorrelations (AnitaPol::AnitaPol_t pol) |
| Bool_t | useCombo (Int_t ant1, Int_t ant2, Int_t phiSector, Int_t deltaPhiSect) |
| void | fillCombosToUse () |
| void | do5PhiSectorCombinatorics () |
| Double_t | getInterpolatedUpsampledCorrelationValue (AnitaPol::AnitaPol_t pol, Int_t combo, Double_t deltaT) const |
Public Attributes | |
| std::complex< Double_t > | ffts [AnitaPol::kNotAPol][NUM_SEAVEYS][((NUM_SAMP *2)/2+1)] |
| FFTs of evenly resampled waveforms. | |
| Double_t | crossCorrelations [AnitaPol::kNotAPol][336][NUM_SAMP *2] |
| Cross correlations. | |
| Double_t | crossCorrelationsUpsampled [AnitaPol::kNotAPol][336][NUM_SAMP *2 *6 *2] |
| Upsampled cross correlations. | |
| Double_t | fVolts [AnitaPol::kNotAPol][NUM_SEAVEYS][NUM_SAMP *2] |
| Hold the filtered waveforms for padding... | |
| Double_t | startTimes [AnitaPol::kNotAPol][NUM_SEAVEYS] |
| Double_t | interpRMS [AnitaPol::kNotAPol][NUM_SEAVEYS] |
| RMS of interpolated TGraphs. | |
| Double_t | interpRMS2 [AnitaPol::kNotAPol][NUM_SEAVEYS] |
| RMS of interpolated TGraphs with extra zero padding. | |
| Int_t | comboIndices [NUM_SEAVEYS][NUM_SEAVEYS] |
| Array mapping ant1+ant2 to combo index. | |
| UInt_t | eventNumber [AnitaPol::kNotAPol] |
| For tracking event number. | |
| Double_t | nominalSamplingDeltaT |
| ANITA-3 => 1./2.6 ns, deltaT for evenly resampling. | |
| Double_t | correlationDeltaT |
| nominalSamplingDeltaT/UPSAMPLE_FACTOR, deltaT of for interpolation. | |
| Int_t | numSamples |
| Number of samples in waveform after padding. | |
| Int_t | numSamplesUpsampled |
| Number of samples in waveform after padding and up sampling. | |
| Int_t | numCombos |
| Number of possible antenna pairs, counted during initialization. Should equal NUM_COMBOS. | |
| std::vector< Int_t > | comboToAnt1s |
| Vector mapping combo index to ant1. | |
| std::vector< Int_t > | comboToAnt2s |
| Vector mapping combo index to ant2. | |
| std::vector< Int_t > | combosToUseGlobal [NUM_PHI] |
| Depends on L3 trigger for global image. | |
| Int_t | multiplyTopRingByMinusOne |
| For showing how I'm an idiot with respect to compiling the ANITA-3 prioritizer. | |
| Int_t | kOnlyThisCombo |
| For debugging, only fill histograms with one particular antenna pair. | |
| Int_t | kDeltaPhiSect |
| Specifies how many phi-sectors around peak use in reconstruction. | |
A class to take in FiteredAnitaEvents and cross-correlate nearby channels.
Definition at line 64 of file CrossCorrelator.h.
